CTDI Phantom CT Dosimetry Phantom

CTDI Phantom CT Dosimetry Phantom Detailed Introduction:

CTDI Phantom CT Dosimetry Phantom

The 3-part CTDI phantom can be used with any CT system and may be used to image and monitor adult head and body, as well as paediatric dose requirements.

A 2-part CTDI dosimetry phantom (adult head and body) is also available.

The phantom set consist of a group of head, body, and paediatric PMMA sections with five probe holes in each section.

They are located in the phantom bodies according to the standard requirements. Acrylic rods are provided to seal the unused holes.

CTDI Phantom CT Dosimetry Phantom Technical specifications：

• Adult Section: Diameter 320 mm, length 150 mm
• Head/Paediatric Body Section: Diameter 160 mm, length 150 mm
• Paediatric Head Section: Diameter 100 mm, length 150 mm
• Each section contains 5 probe insert holes ø13.1 mm (1 center, 4 peripheral, 10 mm from edges)
• Holes can be sealed with adjoining acrylic rods when not in use.
